Key: Carton sealer,Carton sealer machine
Carton sealers are case equipment that seals the top or bottom of a case with tape or glue. Typically, the minor corrugated flaps are kicked and plowed closed as the cases are transferred. As the cases enter the compression section, the major flaps of the carton are closed and a hot-melt adhesive is applied.
Carton sealer machine Total：19 products
- MH-FJ-1A Automatic Carton sealer Machine
- • Top & side belts drive
- • Suitable for heavy products
- Power supply
- 1P 110v/220v 50Hz/60Hz 300W/470W
- Sealing speed
- 30cartons/min
- Carton size
- L(150-∞) x W(120-480) x H(120-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1090) x W(890) x H(1280)mm
- Shipping size
- L(1200) x W(1050) x H(1435)mm
- G.W/N.W
- 250Kg/200Kg
- Optional
- ①Extension roller table ②Feet wheel
③Stainless steel
- MH-FJ-1AW Automatic Carton sealer Machine
- • Side belts drive
- • Suitable for products in light weight
- Power supply
- 1P 110v/220v 50Hz/60Hz 200W/400W
- Sealing speed
- 30cartons/min
- Carton size
- L(150-∞) x W(120-480) x H(120-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1090) x W(890) x H(1280)mm
- Shipping size
- L(1200) x W(1050) x H(1435)mm
- G.W/N.W
- 230Kg/180Kg
- Optional
- ①Extension roller table ②Feet wheel
③Stainless steel
- MH-FJ-1AWS Smart stainless Steel Carton sealer Machine
- • Side belts drive
- • Suitable for products in small box
- Power supply
- 1P 110v/220v 50Hz/60Hz 200W/400W
- Sealing speed
- 30cartons/min
- Carton size
- L(200-∞) x W(95-300) x H(70-300)mm
- Tape size
- 48mm(Kraft or BOPP tape) folded tape 35mm
- Machine size
- L(1090) x W(793) x H(1280)mm
- Shipping size
- L(1150) x W(800) x H(1435)mm
- G.W/N.W
- 230Kg/180Kg
- Optional
- ①Extension roller table ②Feet wheel
③Stainless steel
- MH-FJ-1D Automatic Carton sealer Machine
- • Top & bottom belts drive
- • Suitable for products in light weight
- Power supply
- 1P 110v/220v 50Hz/60Hz 470W/570W
- Sealing speed
- 30cartons/min
- Carton size
- L(150-∞) x W(180-500) x H(120-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(970) x W(890) x H(1280)mm
- Shipping size
- L(1150) x W(1050) x H(1435)mm
- G.W/N.W
- 240Kg/190Kg
- Optional
- ①Extension roller table ②Feet wheel
③Stainless steel
- MH-FJ-1S Automatic Carton sealer Machine
- • Side sealer
- • Top & bottom belts drive
- Power supply
- 1P 110v/220v 50Hz/60Hz 470W/570W
- Sealing speed
- 30cartons/min
- Carton size
- L(150-∞) x W(190-350) x H(120-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(968) x W(1090) x H(1280)mm
- Shipping size
- L(1150) x W(1100) x H(1435)mm
- G.W/N.W
- 240Kg/185Kg
- Optional
- ①Extension roller table ②Feet wheel
③Stainless steel
- MH-FJ-2 Side-band Automatic Carton Sealer Machine
- • Side belts drive
- • Automatically adjust the sealing height and width
- Power supply
- 1P 110v/220v 50Hz/60Hz 470W/570W
- Sealing speed
- 15cartons/min
- Carton size
- L(150-∞) x W(120-500) x H(120-450)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1150) x W(1005) x H(1230)mm
- Shipping size
- L(1200) x W(1100) x H(1400)mm
- G.W/N.W
- 300Kg/250Kg
- Optional
- ①Extension roller table ②Feet wheel
③Guard ④ Stainless steel
- MH-FJ-2CF Pneumatic Carton Sealer and semi case former
- • Side belts drive
- • Automatically adjust the sealing width
- Power supply
- 1P 110v/220v 50Hz/60Hz 400W
- Sealing speed
- 8cartons/min
- Carton size
- L(200-450) x W(200-450) x H(150-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(2000) x W(1005) x H(1230)mm
- Shipping size
- L(2200) x W(1100) x H(1400)mm
- G.W/N.W
- 400Kg/350Kg
- Optional
- ①Extension roller table ②Feet wheel
③Guard ④ Stainless steel
- MH-FJ-3A Automatic Carton Sealer machine
- • Side belts drive
- • Automatically fold the top flaps
- Power supply
- 1P 110v/220v 50Hz/60Hz 400W
- Sealing speed
- 12-15cartons/min
- Carton size
- L(200-550) x W(150-480) x H(127-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1850) x W(988 x H(1370)mm
- Shipping size
- L(2000) x W(1050) x H(1570)mm
- G.W/N.W
- 360Kg/300Kg
- Optional
- ①Feet wheel ②Guard ③ Stainless steel
- MH-FJ-3A With Guard Automatic Carton Sealer
- • Side belts drive
- • Automatically fold the top flaps
- Power supply
- 1P 110v/220v 50Hz/60Hz 400W
- Sealing speed
- 12-15cartons/min
- Carton size
- L(200-550) x W(150-480) x H(127-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1850) x W(988 x H(1370)mm
- Shipping size
- L(2000) x W(1050) x H(1570)mm
- G.W/N.W
- 360Kg/300Kg
- Optional
- ①Feet wheel
- Standard MH-FJ-3AR case sealer
- • Drafting unit of Chinese National Standard of case sealer machine
- • Drafting unit of Chinese National Standard of strapping machine
- • Have passed Moody International ISO9000 Approval in 2002 and passed CE in 2004
- • Occupy over 70% of the market share of China
- Operation:
- a. Adjust the height and width with the height adjustment handle and width adjustment handle. Then switch on the power and the power indicator is alight. Next turn the emergency stop button 2 on the control panel in the arrow direction.
b. Press start button 3 and put on the carton manually. The pendulum automatically fold the cover and the side drive device drive the carton forward until it reaches the cassette mechanism position, the machine seal the carton. - Characteristic and strong point:
- a. Powerfully driven by left and right belt at the bottom.
b. Automatically adjust the sealing height and width & fold the cover.
c. It can match hot glue machine. - Power:
- 1φ220V 50Hz 600W
- Carton size:
- L(200-550)×W(150-470)×H(120-450)mm3
- Work speed:
- 12cartons/min
- Tape material:
- Kraft or BOPP
- bottom Tape size:
- 48-72mm, top using hotmelt machine.
- Machine size:
- L(1950)×W(986)×H(1430)mm3
- Packing size (Normal):
- L(2300)×W(1050)×H(1545)mm3
- Net weight:
- 370Kg
- Gross weight (Normal):
- 440Kg
- Gross weight (Disassembly):
- 425Kg
- Option:
- Extension roller table: L(500)
- FOB3900USD for stainless steel.
- MH-FJ-3B Side-band Automatic Carton sealer
- • Automatically fold the top flaps
- • Automatically adjust the sealing height and width
- • Suitable to connect to the full automatic packaging line
- Power supply
- 3P 380V 50Hz/60Hz 800W
- Sealing speed
- 12cartons/min
- Carton size
- L(250-600) x W(180-450) x H(150-450)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(2100) x W(1050) x H(1750)mm
- Shipping size
- L(2150) x W(1100) x H(2000)mm
- G.W/N.W
- 640Kg/550Kg
- Optional
- ①Feet wheel ②Guard ③ Electric control box
- MH-FJ-3C Automatic Carton Sealer machine
- • Suitable for the cartons with extra width,extra height and extra length
- • Fold the top of cartons automatically
- Power supply
- 3P 380V 50Hz/60Hz 1370W
- Sealing speed
- 8-10cartons/min
- Tape size
- 48-72mm(Kraft or BOPP tape)
- MH-FJ-3D Automatic Carton Sealer machine
- • Suitable for large-sized packages
- • With the automatic box nailing machine(Automatic nailing up and down or sealing cartons up and down is optional)
- • Fold the top of cartons automatically
- Power supply
- 3P 380V 50Hz/60Hz 1370W
- Sealing speed
- 8-10cartons/min
- Tape size
- 48-72mm(Kraft or BOPP tape)
- MA Mini Automatic Carton Sealer machine
- Power supply
- 220V 50HZ 200W
- Carton size
- L150-∞ W120-500 H120-500mm
- Conveying speed
- 22 meters/min
- Tape type
- Kraft paper or BOPP
- Adhesive tape size
- 48mm(48-72mm) optional
- Weight
- 90kg
- Worktable height
- 750mm
- Machine size
- L850 x W880 x H1200mm(the height depends on the carton size)
- Optional
- ①Extension roller table
- MD Mini Automatic Carton Sealer machine
- Power supply
- 220V 50HZ 200W
- Carton size
- L150-∞ W180-500 H120-500mm
- Conveying speed
- 16.7 meters/min
- Tape type
- Kraft paper or BOPP
- Adhesive tape size
- 48mm(48-72mm) optional
- Weight
- 120kg
- Worktable height
- 750mm
- Machine size
- L850 x W780 x H1270mm(the height depends on the carton size)
- Optional
- ①Extension roller table
- MH-FJ-P1 Corner-type Full Automatic Carton Sealer Machine
- • Auto sealing top bottom edges
- • Manual adjusted carton sizes
- Power supply
- 1P 110V/220V 50Hz/60Hz 1000W
- Sealing speed
- 12-15cartons/min
- Carton size
- L(200-500) x W(350-700) x H(200-500)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(2200) x W(1280) x H(1400)mm
- Shipping size
- L(2250) x W(1330) x H(1600)mm
- G.W/N.W
- 550Kg/480Kg
- Optional
- ①Feet wheel ②Guard
- YS-501AW Automaic Carton Sealer
- • Side belts drive
- • Suitable for products in light weight
- Power supply
- 1P 110V/220V 50Hz/60Hz 200W
- Sealing speed
- 30cartons/min
- Carton size
- L(150-∞) x W(120-480) x H(130-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1090) x W(880) x H(1165)mm
- Shipping size
- L(1628) x W(930) x H(1265)mm
- G.W/N.W
- 220Kg/170Kg
- Optional
- ①Extension roller table ②Feet wheel
③ Stainless steel
- YS-501D Automaic Carton Sealer
- • Top & bottom belts drive
- • Suitable for products in light weight
- Power supply
- 1P 110V/220V 50Hz/60Hz 200W
- Sealing speed
- 30cartons/min
- Carton size
- L(150-∞) x W(180-500) x H(120-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1150) x W(890) x H(1280)mm
- Shipping size
- L(1150) x W(1050) x H(1435)mm
- G.W/N.W
- 240Kg/190Kg
- Optional
- ①Extension roller table ②Feet wheel
③ Stainless steel
- YS-502 Automaic Carton Sealer
YS-502 Stainless Steel Automatic Carton Sealer - • Side belts drive
- • Suitable for products in light weight
- •Automatically adjust the sealing height and width
- Power supply
- 1P 110V/220V 50Hz/60Hz 400W
- Sealing speed
- 20cartons/min
- Carton size
- L(150-∞) x W(120-480) x H(130-480)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(1154) x W(920) x H(1275)mm
- Shipping size
- L(1690) x W(970) x H(1425)mm
- G.W/N.W
- 250Kg/300Kg
- Optional
- ①Extension roller table ②Feet wheel
③ Guard
- YS-503 Bottom belt Automaic Carton Sealer
- • Driven by the top motor and non-bottom sealing
- • Suitable for beverage and beer factory packing
- • High speed producing
- • It can match hot glue machine
- Power supply
- 3P 380V 600W
- Sealing speed
- 50cartons/min
- Carton size
- L(250-450) x W(200-400) x H(250-400)mm
- Tape size
- 48-72mm(Kraft or BOPP tape)
- Machine size
- L(2000) x W(1100) x H(2000)mm
- Table height
- 750mm
- Optional
- ①Extension roller table L(500)mm ②Hot melt
